@ IF (A) |
3 |
|---|---|
@ VR (V) |
800 |
Configuration |
Single |
Forward VoltageDrop VF(V) |
1.7 |
MaximumAverageRectifiedCurrent IO (A) |
3 |
Maximum Peak Forward Surge Current IFSM (A) |
150 |
Maximum ReverseCurrent IR (µA) |
5 |
Peak RepetitiveReverse VoltageVRRM (V) |
800 |
Product Type |
ULTRA-FAST RECOVERY RECTIFIER |
AEC Qualified |
No |
Reverse RecoveryTime trr (ns) |
75 |
TotalCapacitance CT (pF) |
50 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2770 | 2025-10-30 | 2025-10-30 | Add Fab Site Code, Country of Diffusion (COD) and Assembly Site Origin (ASO) on Product and Shipping Labels for all Diodes Products |
