KBJL1010

10A Standard Recovery Bridge Rectifier

Datasheet

Contact Sales

Feature(s)

Glass Passivation Die Construction
Ideal for Printed Circuit Board
High Surge Current Capability
UL Listed Under Recognized Component Index, File Number E95060
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative. https://www.diodes.com/quality/product-definitions/

Application(s)

TV power
Game power
PC power

Specifications & Technical Documents

Product Parameters

Compliance (Only Automotive Supports PPAP)	Standard
AEC Qualified	Yes
Forward VoltageDrop V_F(V)	1
TotalCapacitance C_T(pF)	48 pF
MaximumAverageRectifiedCurrent I_O(A)	10 A
Peak RepetitiveReverse VoltageV_RRM(V)	1000 V
Maximum Peak Forward Surge Current I_{FSM (A)}	150 A
Maximum ReverseCurrent I_R(µA)	10 µA

Technical Documents

Recommended Soldering Techniques

TN1.pdf

Purchase & Availability

Something went wrong with your request. Please try again later. If this problem continues, please contact Diodes support for assistance.

Product Change Notices (PCNs)

A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.

PCN #	Issue Date	Implementation Date	Subject
PCN-2658	2024-02-12	2024-05-12	Wafer Diameter Change from 4 inch to 5 inch at Diodes Internal Wafer Fabrication WX1 in WuXi, China for Select Discrete Products
PCN-2620	2023-05-10	2023-08-10	Qualification of Additional Wafer Source and Additional Assembly and Test Site for Select Discrete Products
