GBL210

2A GLASS PASIVATED BRIDGE RECTIFIER

Contact Sales

Feature(s)

Glass Passivated Die Construction
Rating to 1000V PRV
Ideal for Printed Circuit Board
Reliable Low-Cost Construction Utilizing Molded Plastic
UL Recognized File # E94661
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative. https://www.diodes.com/quality/product-definitions/

Compliance (Only Automotive Supports PPAP)	Standard
AEC Qualified	Yes
Forward VoltageDrop V_F(V)	0.95
TotalCapacitance C_T(pF)	45 pF
MaximumAverageRectifiedCurrent I_O(A)	2 A
Peak RepetitiveReverse VoltageV_RRM(V)	1000 V
Maximum Peak Forward Surge Current I_{FSM (A)}	120 A
Maximum ReverseCurrent I_R(µA)	5 µA

Recommended Soldering Techniques
