DSR8F600PI (NRND)

NRND = Not Recommended for New Design

600V 8A HYPERFAST RECTIFIER

Datasheet

Contact Sales

Description

The 8A, 600V DSR8F600PI rectifier is designed specifically for use as a boost diode in power factor correction (PFC) applications. Its soft, very fast-switching characteristics make it ideal for use in hard switching and continuous conduction mode (CCM) PFC circuits.

Feature(s)

Very Fast tRR Reduces MOSFET PFC Switching Losses
Soft Switching Ensures Ringing and EMI are Reduced
Low QRR and IRM Minimize Boost Diode Recovery Losses
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative. https://www.diodes.com/quality/product-definitions/

Application(s)

High Power SMPS
Servers and Telecom Equipment
Flat-Panel TVs

Specifications & Technical Documents

Product Parameters

Forward VoltageDrop V_F(V)	3.2
MaximumAverageRectifiedCurrent I_O(A)	8
Maximum Peak Forward Surge Current I_{FSM (A)}	70
Maximum ReverseCurrent I_R(µA)	20
Peak RepetitiveReverse VoltageV_RRM(V)	600
AEC Qualified	No
Reverse RecoveryTime trr (ns)	30
TotalCapacitance C_T(pF)	22

Technical Documents

Recommended Soldering Techniques

TN1.pdf

RoHS CofC

RoHSFile

Purchase & Availability

Something went wrong with your request. Please try again later. If this problem continues, please contact Diodes support for assistance.

Product Change Notices (PCNs)

A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.

PCN #	Issue Date	Implementation Date	Subject
PCN-2770	2025-10-30	2025-10-30	Add Fab Site Code, Country of Diffusion (COD) and Assembly Site Origin (ASO) on Product and Shipping Labels for all Diodes Products
PCN-2561	2022-02-17	2022-08-17	Device End of Life (EOL)
