DMNH6035SPDWQ

60V 175°C Dual N-Channel Enhancement Mode MOSFET

Datasheet

Contact Sales

Description

This MOSFET is designed to meet the stringent requirements of Automotive applications. It is qualified to AEC-Q101, supported by a PPAP.

Feature(s)

Rated to +175°C – Ideal for High Ambient Temperature Environments
100% Unclamped Inductive Switch (UIS) Test in Production
Low RDS(ON) – Minimizes On State Losses
Low Input Capacitance
Wettable Flank for Improved Optical Inspections

Application(s)

Backlighting
Power Management Functions
DC-DC Converters

Specifications & Technical Documents

Product Parameters

Compliance (Only Automotive Supports PPAP)	Automotive
AEC Qualified	Yes
Polarity	N+N
ESD Diodes (Y\|N)	No
\|V_DS\| (V)	60 V
\|V_GS\| (±V)	20 ±V
\|I_DS\| @T_C = +25°C (A)	33 A
P_D @T_A = +25°C (W)	2.4 W
P_D @T_C = +25°C (W)	68 W
R_DS(ON)Max@ V_GS(10V) (mΩ)	35 mΩ
R_DS(ON)Max@ V_GS(4.5V) (mΩ)	44 mΩ
\|V_GS(TH)\| Max (V)	3 V
Q_G Typ @ \|V_GS\| = 10V (nC)	16 nC
C_ISS Typ (pF)	879 pF
C_ISS Condition @\|V_DS\| (V)	25 V

Technical Documents

SPICE Model

DMNH6035SPDWQ.spice.txt

Recommended Soldering Techniques

TN1.pdf

RoHS CofC

RoHSFile

Purchase & Availability

Something went wrong with your request. Please try again later. If this problem continues, please contact Diodes support for assistance.

Product Change Notices (PCNs)

A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.

PCN #	Issue Date	Implementation Date	Subject
PCN-2770	2025-10-30	2025-10-30	Add Fab Site Code, Country of Diffusion (COD) and Assembly Site Origin (ASO) on Product and Shipping Labels for all Diodes Products
