fT (MHz) |
4 |
|---|---|
fT (MHz) |
4 |
hFE (min) |
20 |
hFE(@ IC) |
1 |
hFE(@ IC2) |
2 |
hFE(Min 2) |
11 |
IC (A) |
3.2 |
ICM (A) |
6.4 |
PD (W) |
20 |
Product Type |
NPN |
AEC Qualified |
No |
RCE(SAT) |
N/A |
VCE (SAT) (@ IC/IB) (A/m A) |
1/200 |
VCE (SAT) (@ IC/IB2) (A/mA) |
2/500 |
VCE (SAT)(Max.2) |
600 |
VCE (SAT)Max (mV) |
300 |
VCEO, VCES (V) |
700 |
Something went wrong with your request. Please try again later. If this problem continues, please contact Diodes support for assistance.
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2770 | 2025-10-30 | 2025-10-30 | Add Fab Site Code, Country of Diffusion (COD) and Assembly Site Origin (ASO) on Product and Shipping Labels for all Diodes Products |
| PCN-2453 | 2020-04-07 | 2020-10-07 | Device End of Life (EOL) |
