Application

Suitable for AC to DC bridge full wave rectification for SMPS, LED lighting, adapter, battery charger, home appliances, office equipment, and telecommunication applications.

Features

  • Glass Passivated Die Construction
  • Miniature Package Saves Space on PC Boards
  • High Current Capability
  • Ideal for SMT Manufacturing
  • Low Forward Voltage Drop
  • Lead-Free Finish; RoHS Compliant
  • Halogen and Antimony Free. “Green” Device

Product Specifications

Product Parameters

Forward Voltage Drop VF (V) 1.1
Qualified to AECQ10x No
Automotive Compliant PPAP No
Total Capacitance CT 17 pF
Maximum Average Rectified Current IO 1.5 A
Peak Repetitive Reverse Voltage VRRM 1000 V
Maximum Peak Forward Surge Current IFSM 50 A
Maximum Reverse Current IR 5 µA

Technical Documents

Recommended Soldering Techniques

TN1.pdf

Orderable Part Number Authorized Distributor Quantity Inventory Date Buy Online Region
ABS10B-13 Mouser Electronics Inc. 4714 8/3/2020 Buy Now United States
ABS10B-13 Digi-Key Electronics 2275 8/2/2020 Buy Now United States
