G10H150CTFW (Not Recommended for new design)

NRND = Not Recommended for New Design

Contact Sales

Log in or register to manage email notifications about changes to datasheets or PCNs for this part.


  • Super Low Forward Voltage Drop
  • Reliable High Temperature Operation
  • Softest, fast switching capability
  • Qualified according to AEC-Q101 Rev_D
  • Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
  • Halogen and Antimony Free. “Green” Device (Note 3)


  • Devices optimized for ultra-low forward voltage drop to maximize efficiency in Power Supply applications

Product Specifications

Product Parameters

@ VR (V) 150
Compliance (Only Automotive supports PPAP) Standard
Configuration Dual
Forward VoltageDrop VF(V) 0.79
MaximumAverageRectifiedCurrent IO (A) 10
Maximum ReverseCurrent IR (µA) 8
Peak ForwardSurge CurrentIFSM(A) 180
Peak RepetitiveReverse VoltageVRRM (V) 150
AEC Qualified Yes

Related Content


Technical Documents

Recommended Soldering Techniques


Product Change Notices (PCNs)

A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.

PCN # Issue Date Implementation Date Subject
PCN-2579 2022-08-29 2023-02-28 Device End of Life (EOL)
