P-Channel Enhancement Mode MOSFET
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| Compliance (Only Automotive Supports PPAP) | Standard |
|---|---|
| AEC Qualified | No |
| Polarity | P |
| ESD Diodes (Y|N) | Yes |
| |VDS| (V) | 12 V |
| |VGS| (±V) | 8 ±V |
| |IDS| @TA = +25°C (A) | 7.2 A |
| PD @TA = +25°C (W) | 1.4 W |
| RDS(ON)Max@ VGS(4.5V) (mΩ) | 18 mΩ |
| RDS(ON)Max@ VGS(2.5V) (mΩ) | 22 mΩ |
| RDS(ON)Max@ VGS(1.8V) (mΩ) | 28 mΩ |
| |VGS(TH)| Min (V) | 0.35 V |
| |VGS(TH)| Max (V) | 1 V |
| QG Typ @ |VGS| = 4.5V (nC) | 27 nC |
| CISS Typ (pF) | 2847 pF |
| CISS Condition @|VDS| (V) | 4 V |
