1.5A GLASS PASSIVATED BRIDGE RECTIFIER
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| Compliance (Only Automotive Supports PPAP) | Standard |
|---|---|
| AEC Qualified | No |
| Forward VoltageDrop VF(V) | 1.1 |
| MaximumAverageRectifiedCurrent IO (A) | 1.5 A |
| Peak RepetitiveReverse VoltageVRRM (V) | 800 V |
| Maximum Peak Forward Surge Current IFSM (A) | 50 A |
| Maximum ReverseCurrent IR (µA) | 10 µA |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2549 | 2021-10-19 | 2022-04-19 | Device End of Life (EOL) |
