ULN2003A

Contact Sales

Log in or register to manage email notifications about changes to datasheets or PCNs for this part.

Description

The ULN2002A, ULN2003A and ULN2004A are high voltage, high current Darlington arrays each containing seven open collector common emitter pairs. Each pair is rated at 500mA. Suppression diodes are included for inductive load driving, the inputs and outputs are pinned in opposition to simplify board layout.

Device options are designed to be compatible with common logic families:

ULN2002A (14-25V PMOS)
ULN2003A (5V TTL, CMOS)
ULN2004A (6-15V CMOS, PMOS)

These devices are capable of driving a wide range of loads including solenoids, relays, DC motors; LED displays filament lamps, thermal print-heads and high power buffers.

The ULN2002A, 2003A and 2004A are supplied in a small outline 16 pin package (SO-16).

Feature(s)

  • 500mA rated collector current (single output)
  • High voltage outputs: 50V
  • Output clamp diodes
  • Inputs compatible with popular logic types
  • Relay driver applications
  • “Green” Molding Compound (No Br, Sb)
  • Totally Lead-Free & Fully RoHS Compliant
  • Halogen and Antimony Free. “Green” Device

Application(s)

  • Relay Driver
  • Stepping Motor Driver
  • Home Appliance
  • Industrial Application

Product Specifications

Product Parameters

Numberof Drivers 7
Input Compatibility 5V TTL CMOS
InputVoltageMax (V) 30 V
Collector to EmitterVoltage Rating (V) 50 V
OutputVoltage Max (V) 50 V
OutputCurrentMax (mA) 500 mA
DelayTime Typ (ns) 250 ns
OperatingTemperatureRange  (°C) -40 to 105 °C
