DML3011LFDS

Description

The DIODES™ DML3011LFDS load switch provides a component and area-reducing solution for efficient power domain switching. In addition to integrated control functionality with ultra-low on−resistance, this device offers system safeguards and adjustable Slew Rate control signaling. This cost effective solution is ideal for power management and hot-swap applications requiring low power consumption in a small footprint.

Feature(s)

• Advanced Controller with Charge Pump
• Integrated N-Channel MOSFET with Ultra Low R_ON
• Input Voltage Range5V to 20V
• Adjustable Soft-Start via Controlled Slew Rate
• Thermal Shutdown
• V_IN Under-Voltage Lockout
• Short-Circuit Protection
• Extremely Low Standby Current
• Load Bleed (Quick Discharge)
• Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
• Halogen and Antimony Free. “Green” Device (Note 3)
• For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative.

https://www.diodes.com/quality/product-definitions/

Application(s)

• Portable electronics and systems
• Notebook and tablet computers
• Telecom, networking, medical, and industrial equipment
• Set−top boxes, servers, and gateways
• Hot−swap devices and peripheral ports
