This new generation TVS is designed to protect sensitive electronics
from the damage due to ESD. The combination of small size and high-
ESD surge capability makes it ideal for use in portable applications
such as cellular phones, digital cameras, and MP3 players.


- Provides ESD Protection per IEC 61000-4-2 Standard: Air ±30kV, Contact ±30kV
- 1 Channel of ESD Protection
- Low Channel Input Capacitance
- Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
- Halogen and Antimony Free. “Green” Device (Note 3)


-  Cellular Handsets
- Portable Electronics
- Computers and Peripheral

Product Specifications

Product Parameters

Compliance (Only Automotive supports PPAP) Standard
Maximum Peak Pulse Current IPP @ 8x20±s Max 12
AEC Qualified Yes
Configuration Single (Uni-Directional)
Channel Input CapacitanceCT Typ(pF) 70 pF
Reverse Standoff Voltage VRWM(V) 3.3 V
Breakdown VoltageVBR Min(V) 5 V
Typ Reverse Leakage Current IR @ VRWM Max(µA) 0.1 µA
Maximum Clamping Voltage @ MaxPeak Pulse CurrentVC(V) 10 V
VESD IEC61000-4-2 Contact Discharge(kV) 30 kV
